Heat Resistant PVC Insulated High-Flexible EV Charging Cable for Electric Vehicle Charging Stations

Gambar besar : Heat Resistant PVC Insulated High-Flexible EV Charging Cable for Electric Vehicle Charging Stations

Detail produk:

Sertifikasi:	ISO9001, CCC, RoHS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	3.000
Harga:	0.5

Kontak

Detil Deskripsi produk

Bahan konduktor:	Tembaga	Bahan selubung:	PVC
Bahan isolasi:	PVC	Bentuk material:	Kawat bundar
Nilai Tegangan:	450/750V AC	Suhu terukur:	-40ºC-90ºC
Resistensi api:	IEC60332-1-3, FT1, FT2	Uji tegangan:	DC 2,5kV/15 menit (kabel listrik), DC 1,5kV/15 menit (kabel sinyal)
Tipe Konduktor:	Tembaga terdampar, kaleng atau telanjang	Jenis isolasi:	Elastomer termoplastik
Konfigurasi Perakitan:	10~70(2~5core)+0,5~0,75P)(1~10core)	Jenis sarung:	Tpe
Ketahanan Minyak:	Ya	Resistensi UV:	Ya
Bukti Kelembaban:	Ya
Menyoroti:	Heat Resistant EV Charging Cable , PVC Insulated Electric Vehicle Charging Cable , High-Flexible EV Power Cable

EVJT Electric Vehicle Charging Cable

Multicore PVC insulated heat resistant EV charging cable designed for reliable electric vehicle charging applications.

Key Advantages

High-flexible design capable of repeated bending
Oil resistant construction
UV resistant for outdoor applications
High-flame resistance
Moisture-proof protection

Application Range

Connection wire between EV AC charging equipment
EV AC Charging stations and AC Charging piles

Cable Construction

Conductor: Stranded, tinned or bare copper
Insulation: Thermoplastic Elastomer
Assembly: 10~70(2~5 cores) + 0.5~0.75P(1~10 cores)
Non-woven wrap
Sheath: TPE (Thermoplastic Elastomer)

Compliance Standards

CQC1103~1105-2015
RoHS Compliant
REACH Compliant

Technical Specifications

Rated Voltage	450/750V AC
Temperature Range	-40ºC to 90ºC
Flame Resistance	IEC60332-1-3, FT1, FT2
Voltage Withstand Test (Power Wire)	1.0~70mm²: DC 2.5kV/15min
Voltage Withstand Test (Signal Wire)	0.5~0.75mm²P: DC 1.5kV/15min
