UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable

UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable

Gambar besar :  UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable

Detail produk:
Tempat asal: CINA
Nama merek: HWATEK
Sertifikasi: ISO9001, RoHS
Nomor model: UL2587
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1000
Harga: negotiable
Kemasan rincian: Gulungan atau gulungan
Waktu pengiriman: 4 minggu
Syarat-syarat pembayaran: T/t
Kontak
Detil Deskripsi produk
Tegangan Dinilai: 600v Suhu pengenal: 90ºC
Bahan konduktor: Tembaga kaleng terdampar Bahan selubung: PVC
Bahan isolasi: PVC Unit kabel: 2p × 20awg
Kekuatan tarik: ≥10.3mpa Pemanjangan: ≥100%
Kondisi tua: 121 ± 1 ℃ × 168H Ketebalan jaket: 0.76mm
Diameter kabel: 6,50 ± 0,30mm Spec: HT2502502
Menyoroti:

Copper Conductor EV Charging Cable

,

TPE Sheath Electric Vehicle Charging Cable

,

Flame Retardant EV Power Cable

UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable
Product Specifications
Construction
Conductor Tinned copper standard
Cross section 2P×20AWG
Construction 65/0.10mm
Strand Dia.(Ref.) 0.93mm
Insulation PVC
Nom.Thickness 0.23mm
Min.Thickness 0.18mm
Insulation Dia. 1.40±0.08mm
Insulation colour 1.black&red 2.white&green
Twisted(Ref.) 2.80mm
Filler Optional
Material Al-mylar
Assembly 2P×20AWG+A
Jacket PVC
Nom.Thickness 0.76mm
Min.Thickness 0.61mm
Outer Dia. 6.50±0.30mm
Colour per request
Electrical Characteristics & Physical Properties
Mechanical Performance
  Jacket
Material PVC
Tensile strength ≥10.3MPa
Elongation ≥100%
Aged condition 121±1℃×168h
Percent of original tensile strength ≥70%
Percent of original elongation ≥65%



Insulation:PVC
Conductor : Tinned copper stranded
Construction:65/0.10mm

Jacket : per request

Jacket: PVC

Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,

Standards
International: UL2587
RoHS,REACH Compliant,

Technical data
Rated voltage:600V
Rated Temperature: 90℃
Voltage withstand test:AC 2.0 kV/1min

Properties
Effectively resist electromaganetic interference
Excellent insulation performance
UL758-E258652-20060111A-CertificateofCompliance(2)...UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 0UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 1



Company Profile

Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14,980 square meters. In 2020 we established our Nantong facility with 100 million RMB capital investment covering 34,000 square meters.

With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certifications. We serve global customers across various industries through our well-established sales system based on the management principles of HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.

UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 2
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 3
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 4
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 5
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 6
UL2587 TYPE PVC insulation Tinned Copper Stranded PVC Sheath 2P×20AWG 90℃ 600V high Voltage cable 7
Frequently Asked Questions
Q: What products do you supply?

A: We produce consumer electronics wires, hook-up wires, industrial cables, robot cables, EV charging cables, and new/green energy cables.

Q: What certifications do you have?

A: We hold UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, and ETL certifications.

Q: Can we get samples before ordering?

A: Yes, we can arrange samples for evaluation.

Q: What's your lead time?

A: Standard lead time is 2-3 weeks, extending to 5-6 weeks during peak seasons.

Q: How do you guarantee product quality?

A: We conduct pre-production sampling and final inspection before shipment to ensure quality standards.
