Customized 42 AWG Medical Device Cable with Silver Plate Copper PTFE Sheath and PFA Insulation

Gambar besar : Customized 42 AWG Medical Device Cable with Silver Plate Copper PTFE Sheath and PFA Insulation

Detail produk:

Sertifikasi:	ISO9001, CE, CCC, RoHS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	100 meter

Kontak

Detil Deskripsi produk

Bahan konduktor:	Tembaga pelat perak	Bahan selubung:	Ptfe
Bahan isolasi:	PFA	Bentuk material:	Kawat bundar
Ukuran kabel:	42AWG	Konstruksi:	7/0,025mm
Diameter untai:	0,075mm	Ketebalan isolasi:	0,10mm
Diameter Isolasi:	0,27 ± 0,05mm	Diameter perakitan akhir:	7.30mm
Ketebalan jaket:	0.60mm	Diameter luar:	9,40 ± 0,30mm
Suhu pengenal:	60 ° C.	Nilai Tegangan:	30V
Paket Transportasi:	500m/reel
Menyoroti:	Silver Plate Copper Medical Device Cable , PTFE Sheath Medical Device Cable , PFA Insulation Medical Device Cable

Customized 42 AWG and 75 Ohms Medical Device Cables

Product Specifications

Conductor: Silver plate copper alloy Jacket
Size: 42AWG
Construction: 7/0.025mm
Strand Dia: 0.075mm
Insulation: Foam PFA
Nom.Thickness: 0.10mm
Insulation Dia: 0.27±0.05mm
Insulation colour: Natural
Spiral Tinned copper alloy, 0.0254mm, ≥90%
Inner jacket Pet tape, ≥25%
Colour options: White (A1,A4,A5), Black (A2,A6,A7), Red (A3,A8,A9), Blue (A10,A11,A12)
Assembly-A: 16Cx42AWG
Final assembly: 12×Assembly-A+Filler
Final assembly Dia. nom.: 7.30mm
Material: PTFE tape, ≥25%
Braid: Tinned copper tinsel, 0.11mm, ≥95%
Jacket: PVC
Nom.Thickness: 0.60mm
Outer Dia.: 9.40±0.30mm
Colour: White (standard, customizable)

Technical Specifications

Reference standard: NOUL
Product Category: NOUL192Cx42AWG(60pF)
Rated temperature: 60°C
Rated voltage: 30V
Conductor: Silver plate copper alloy
Insulation material: Foam PFA
Sheath material: PVC

Customization Options

Detailed dimensions are subject to product specifications
Other specifications can be designed and manufactured according to customer requirements
Standard sheath color is black, customizable upon request
